Description:

Designed for the most demanding landscape maintenance professionals, the Exmark Lazer Z X-Series represents the pinnacle of commercial zero-turn mowers. With advanced features and options, it delivers exceptional performance, comfort, and durability.

Cutting Deck Options:

• 96-inch UltraCut Flex Wing Cutting Deck
• UltraCut Series 6 Decks available in:
• 52-inch
• 60-inch
• 72-inch
• Adapt Technology: Select models come equipped with Adapt Technology to enhance cut quality.

Engine Options:

• Rugged Commercial-Grade Engines
• Electronic Fuel Injection (EFI) Options with:
• EGov Technology
• RED Technology (Boosts fuel efficiency by up to 41%)

Features:

• Cutting Deck Widths:
• 52 inches
• 60 inches
• 72 inches
• 96 inches
• Comfort: Full-suspension seating system
• Control: Smooth, easy-to-use controls for precision maneuverability

Value:

• Combination of Power, Productivity, and Durability
• Top-of-the-Line Gasoline-Powered Mower

Specification:

General Information

• UPC: 193308225418
• Engine Brand: Kawasaki
• Engine Model: FX921V
• Engine Displacement: 999 cc
• Engine Series: V-Twin
• Engine Speed: 3,750 RPM
• Fuel Type: Gas Carbureted
• Carb Compliant: No
• Speed: Infinitely variable speed selection from 0–11.5 mph (18.5 km/h) forward, 0–7.0 mph (11.3 km/h) reverse
• Transmission: Hydrostatic
• Drive: Hydro-Drive
• Transmission Speeds: Infinitely Variable
• Drive Description: Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter, and heavy-duty components. 16 cc pumps and 17.1 cubic inch motors.
• Fuel Capacity: 12-gallon (45.4-L), single fuel tank with single fill location.
• Fuel Indicator: Yes - electronic Sender

Starter and Electrical

• Starter: Electric
• Electrical: 12-volt battery with 15-amp alternator

Engine Specifications

• Engine Spec: FX921V-_S04-R
• Air Filter: Heavy-duty canister air filtration system

Dimensions and Weight

• Width: 72.8 in. (184.9 cm)
• Height: 70.5 in. (179.1 cm)
• Length: 83.1 in. (211.1 cm)
• Curb Weight: 1256 lbs

Cutting Deck

• Deck Width: 60 in.
• Deck Style: Floating Deck
• Deck Style Description: Full-floating UltraCut Series 6 with heavy-duty spindle. Side discharge standard with the option to bag or mulch.
• Deck Construction: 10-gauge top, formed and continuously seam welded; 7-gauge side skirt; 7-gauge formed and welded spindle mounting locations
• Cutting Heights: 1.0 in. (2.5 cm) to 5.5 in. (11.8 cm) in 0.25 in. (0.64 cm) increments adjustable from operator’s seat.
• Blade Tip Speed: Approximately 18,500 fpm
• Blades: 3 Blades at 20.50 in. Length

Tires and Wheels

• Caster Forks: 0.50 in. thick caster yoke arms
• Front Caster Tires: 13 x 6.5-6 smooth tread, semi-pneumatic
• Drive Tires: 24 x 12.0-12, 4-ply Turf Master®

Frame and Construction

• Tractor Frame: Unibody, welded, heavy-duty 1.5 in. x 3 in. tubular steel
• Blade Spindles: No maintenance, sealed and non-greasable spindles; 7.75 in. diameter cutter housing with 30mm (1.18 in.) diameter spindle shaft, double row bearings, top and bottom, and splined blade driver.

Controls and Features

• Steering Control: Hydraulically dampened twin levers, adjustable fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.
• Parking Brake: Lever-actuated disc brake
• Deck Lift: Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles or place in transport position. Equipped with Adapt system.
• Drive Wheel Release: Allows unit movement without engine running.
• PTO Engagement: MagStop Electromagnetic 250-ft-lb clutch with spot brake
• Seat: Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on an innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
• Standard Features: Engine hour meter and cup holder

Safety and Compliance

• Safety Package: Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
• ROPS: 2-post foldable ROPS standard with seat belt and latch

Width	Weight	Height	Length
72.8 Inch	1256 Pounds	70.5 Inch	83.1 Inch
